A101
A101Model:A101Project nameA101Sell Point10.1"HD DesignForm FactorBar type、Multi-point touchAntennaInter
A101Model:A101Project nameA101Sell Point10.1"HD DesignForm FactorBar type、Multi-point touchAntennaInter
A101 | ||
Model:A101 | ||
Project name | A101 | |
Sell Point | 10.1"HD | |
Design | ||
Form Factor | Bar type、Multi-point touch | |
Antenna | Internal | |
Materials | Plastics | |
Dimension(L*W*H)(mm) | W240.8*L167.5*H8.7MM | |
Weight | TBD | |
Display | Screen Numbers | Single |
Main Display Size | TBD | |
Main Display Resolution | 10.1" 1280*800 | |
Main Display Colours | TBD | |
Main Display Technology | TFT | |
Connection mode | ZIF connector(RGB ) | |
Touch Screen | Capacitive (5 points) | |
Keypad Design | Keypad type | Vitual Keypad |
Keypad | Volume+/- key, Power key,Reset key | |
Shortcut key | Android standard key | |
Standby | Standby Type | Dual sim card dual standby |
Standby I | 3G Standards | WCDMA |
3G Frequency | 850/900(Alternative)、1900MHz/2100MHz(Alternative or both) | |
3G Data Rates | HSDPA | |
2G Standards | GSM/GPRS/EDGE | |
2G Frequency | 850/900/1800/1900Mhz(Quad band) | |
2G Data Rates | GPRS/EDGE | |
Standby II | 2G Standards | GSM/GPRS/EDGE |
2G Frequency | 850/900/1800/1900Mhz(Quad band) | |
2G Data Rates | GPRS/EDGE | |
Platform Information | Baseband Chipset | SC7730 |
Baseband Chipset CPU Frequency | 1.3GHZ Quad-core | |
2G Baseband Chipset | N/A | |
Special Chipset | N/A | |
RAM | 2GB | |
ROM | 32GB | |
Extend Storage | Micro-SD 8pin | |
WIFI | WLAN 802.11b/g/n | |
GPS | GPS | |
Bluetooth | Yes | |
ATV/DTV | ATV(NTSC/PAL/SECAM) /DTV(ISDB-T) | |
light sensor | Yes | |
G+C Sensor | Yes | |
FM | Yes | |
Main Camera | 2.0M | |
Connection mode | FPC | |
Sub Camera | 0.3M | |
Connection mode | FPC | |
Flash LED | Yes | |
Speaker | Single SPK 2415 | |
I/O | Charge I/O | Micro-USB 5pin |
Data tranport I/O | Micro-USB 5pin | |
Headset I/O | 3.5mm | |
USB Data rates | USB 2.0 Full Speed | |
USB Mass Storage | Yes | |
Battery | Battery capability(mAh) | 4000mAh(MAX) |
Battery type | Lithium ion secondary battery | |
Flight Mode | Yes | |
Software | OS | Android 4.4 |
Language | Full Android set | |
Input Method | Android Keypad | |
UI | android standard UI | |
system | Browser | Yes |
Yes | ||
Calendar | Yes | |
Clock | Yes | |
Music | Yes | |
Time zone | yes | |
Calculator | Yes | |
Navigation | Yes | |
App | Multimedia Browser | JPG/JPEG/BMP/GIF/PNG |
Video Play | Yes | |
Audio Play | Yes | |
Task manager | Yes | |
File Explorer | ES File Explorer | |
APP Set Up | APK Manager | |
Camera | yes | |
STK | SIM TOOL | |
Other APP | USB OTG | Yes |
