| A16 |
| Model：A16 |
| Project name | A16 |
| Sell Point | 7"HD |
| Design |
|
| Form Factor | Bar type、Multi-point touch |
| Antenna | Internal |
| Materials | Plastics |
| Dimension(L*W*H)(mm) | W189.7*L109.2*H9.6MM |
| Weight | TBD |
| Display | Screen Numbers | Single |
| Main Display Size | TBD |
| Main Display Resolution | 7" 1200*1920 |
| Main Display Colours | TBD |
| Main Display Technology | IPS |
| Touch Screen | Capacitive (5 points) |
| Keypad Design | Keypad type | Vitual Keypad |
| Keypad | Volume+/- key, Power key，Reset key |
| Shortcut key | Android standard key |
| Standby | Standby Type | Dual sim card dual standby |
| Standby I | 3G Standards | WCDMA |
| 3G Frequency | 850/900（Alternative）2100MHz（Alternative or both）
|
| 3G Data Rates | HSDPA |
| 2G Standards | GSM/GPRS/EDGE |
| 2G Frequency | 850/900/1800/1900Mhz(Quad band) |
| 2G Data Rates | GPRS/EDGE |
| Standby II | 2G Standards | GSM/GPRS/EDGE |
| 2G Frequency | 850/900/1800/1900Mhz(Quad band) |
| 2G Data Rates | GPRS/EDGE |
| Platform Information | Baseband Chipset | MT6589 |
| Baseband Chipset CPU Frequency | 1.3GHZ Quad-core |
| 2G Baseband Chipset | N/A |
| Special Chipset | N/A |
| RAM | 2GB |
| ROM | 32GB |
| Extend Storage | Micro-SD 8pin |
| WIFI | WLAN 802.11b/g/n |
| GPS | GPS |
| Bluetooth | Yes |
| ATV/DTV | ATV(NTSC/PAL/SECAM) /DTV(ISDB-T) |
| light sensor | Yes |
| G+C Sensor | Yes |
| FM | Yes |
| Main Camera | 5.0M |
| Connection mode | FPC |
| Sub Camera | 2.0M |
| Connection mode | FPC |
| Flash LED | Yes |
| Speaker | Single SPK 2415 |
| I/O | Charge I/O | Micro-USB 5pin |
| Data tranport I/O | Micro-USB 5pin |
| Headset I/O | 3.5mm |
| USB Data rates | USB 2.0 Full Speed |
| USB Mass Storage | Yes |
| Battery | Battery capability(mAh) | 3800mAh(MAX) |
| Battery type | Lithium ion secondary battery |
| Flight Mode | Yes |
| Software | OS | Android 6.1 |
| Language | Full Android set |
| Input Method | Android Keypad |
| UI | android standard UI |
| system | Browser | Yes |
| E-mail | Yes |
| Calendar | Yes |
| Clock | Yes |
| Music | Yes |
| Time zone | yes |
| Calculator | Yes |
| Navigation | Yes |
| App | Multimedia Browser | JPG/JPEG/BMP/GIF/PNG |
| Video Play | Yes |
| Audio Play | Yes |
| Task manager | Yes |
| File Explorer | ES File Explorer |
| APP Set Up | APK Manager |
| Camera | yes |
| STK | SIM TOOL |
| Other APP | USB OTG | Yes |
|
|
